JX-TJ450 Coner Pasting Machine

Man-machine interface with PLC system controlling;
Non-stop cardboard quick stacking and conversion device;
The replacement work of the various sizes of the cardboard is easy and fast as well as the mold-replacing work;
Belt-delivering mode for cardboard feeding,fast machine speed for mass production;
Automatic tape-sending,automatic tape cutting and pasting enable four-corner pasted at one time;
Automatic alarming system for running-out alarm for both cardboard and tape.

Inquiry

Product details

Machine Performance

Man-machine interface with PLC system controlling;
Non-stop cardboard quick stacking and conversion device;
The replacement work of the various sizes of the cardboard is easy and fast as well as the mold-replacing work;
Belt-delivering mode for cardboard feeding,fast machine speed for mass production;
Automatic tape-sending,automatic tape cutting and pasting enable four-corner pasted at one time;
Automatic alarming system for running-out alarm for both cardboard and tape.

Main Technical Parameters

Model	JX-TJ450
Max.size of box	450×350×140mm
Min.size of box	50×50×15mm
Max. Paper-board size	650mm×550mm
Work speed	20-50pcs/min.
Machine Dimension(L×W×H)	2300×1200×2100mm
Net weight	1100kgs
Air supply	≧0.6MPA
Power	3kw
