Main Technical Parameters
|
MODEL |
JX-KC1000M |
JX-KC1300M |
|
Feeding Width |
100-980mm |
100-1280mm |
|
Feeding Length |
100-800mm |
100-800mm |
|
Slotting Distance |
0-800mm |
0-1100mm |
|
Precision |
±0.2mm |
±0.2mm |
|
Work Speed |
10-30m/min |
10-30m/min |
|
Cardboard Thickness |
300gsm-4mm |
300gsm-4mm |
|
Grooving Angle |
80°-140° |
80°-140° |
|
Diameter of Drum |
600mm |
600mm |
|
Max.QTY of Groove/time |
9 |
12 |
|
Power |
2.2kw |
2.2kw |
|
Voltage |
AC380V,50Hz |
AC380V,50Hz |
|
Net Weight |
1000kgs |
1200kgs |
|
Dimension(L×W×H) |
1210×1500×1400mm |
1210×1800×1400mm |
