Main Technical Parameters
|
MODEL |
JX-KC1000A |
JX-KC1300A |
|
Feeding Width |
80-900mm |
80-1200mm |
|
Feeding Length |
100-600mm |
100-600mm |
|
Slotting Distance |
0-800mm |
0-1200mm |
|
Precision |
±0.2mm |
±0.2mm |
|
Work Speed |
10-35m/min |
10-35m/min |
|
Cardboard Thickness |
1mm-3.5mm |
1mm-3.5mm |
|
Grooving Angle |
80°-145° |
80°-145° |
|
Diameter of Drum |
600mm |
600mm |
|
Max.QTY of Groove/time |
9 |
12 |
|
Power |
2.3kw |
2.3kw |
|
Voltage |
AC380V,50Hz |
AC380V,50Hz |
|
Net Weight |
1200kgs |
1400kgs |
|
Dimension(L×W×H) |
2180×1500×1500mm |
2180×1800×1500mm |
